Futura+ Udadgående terrassedør

Futura+ Outward opening terrace door

Use

The outward opening terrace door is used in all types of buildings to access a terrace, patio or spacious balcony. It is suitable for rooms with minimal space and is the preferred choice for fire exits with a non-locking handle.

Function

The doors are side hung with concealed hinges and are locked with a single handle on the inside that operates a multi-locking point mushroom bolt mechanism with a night vent position. These doors are available with glazing bars, styling bars or panels as required. Double doors have a French casement floating-mullion. A 15 mm. low threshold is available with this door.

  • Product information:
  • UD: Double: 1,31 W/m²K | Triple: 0,74 W/m²K
  • Glass dimensions: 30 mm (4-22-4) | 44 mm (4-16-4-16-4)
  • Styling bar: 22/22 mm, 53 mm og 116 mm
  • Frame dimensions: 50 x 149 mm / 175 mm
  • Manuals
