Futura+ Side hung window


Side hung windows are used in all types of building and are the most traditional opening method. Side hung opening is the most practical choice for escape windows.


Side hung windows are pivoted from the jamb using butt hinges. The window is locked with a handle that operates a multi locking point hook bolt mechanism and has a night vent position. The handle also operates a friction brake to hold the sash whilst in the open position. A floating mullion is available on windows used in pairs for maximum opening widths, the master leaf is operated by a handle and the slave leaf is held by flush bolts.

  • Product information:
  • Uw: Double: 1,31 W/m²K | Triple: 0,74 W/m²K
  • Glass dimensions: 30 mm (4-22-4) | 44 mm (4-16-4-16-4)
  • Styling bar: 22/22 mm, 53 mm og 116 mm
  • Frame dimensions: 50 x 149 mm / 175 mm
