Nation I Turn Window (Inward opening)

Use:

The Turn window has the most stable locking and is without risk of incorrect operation. Turn windows can typically be recommended for large openings. Frame I / Nation I (inward opening) and Frame IC / Nation IC (outward opening) have the same outer sash-frame height and can therefore be placed in the same elevation, without there being much visual difference. The revolving window can also meet all the building regulations' requirements for egress openings.



Function:

Turn windows are inward opening windows with a side-hung function. The opening function is controlled by a lever handle operating an espagnolette in the side or bottom sash. In the closed position, the handle faces vertically downwards (or horizontally) and the turn function is triggered by turning the handle 90 °. The Turn window can, as an option, be supplied with a handle-operated brake. The brake can, in the side hung function, hold the frame in any position above 18 ° opening.

  • Product information:
  • Uw: 0,82 (Medi g) | 0,85 (High g)
  • Glass dimensions: Triple glazing (48 mm): 4-18-4-18-4
  • Styling bar: 22/23 mm og 42 mm
  • Frame dimensions: 50 x 122 / 149 mm
